IF5000 Fiber Optic Inertial Navigation System – 0.05° secφ North Finding

El IF3000 consta de un sistema integrado de tres ejes. giroscopio de fibra ópticaEste producto cuenta con un acelerómetro de cuarzo y un módulo satelital multifrecuencia completo compatible con la función Beidou. Incorpora excelentes algoritmos de fusión de navegación, que proporcionan información de navegación estable y fiable incluso en caso de pérdida de señal satelital. Tras la compensación y calibración de temperatura, se garantiza la precisión del sistema en todo el rango de temperaturas. Dispone de múltiples interfaces y puede conectarse a sensores como odometría y DVL. Ofrece una buena escalabilidad y permite personalizar diversos protocolos de comunicación.

IF3500 es un sistema desarrollado internamente. sistema de navegación inercial de fibra óptica con un tamaño pequeño y alta precisión, que puede lograr la autodetección del norte a 0,1°El sistema consta de un giroscopio de fibra óptica con una estabilidad de polarización cero de 0,015.°/h, un acelerómetro de cuarzo de alta precisión y un módulo satelital multifrecuencia de sistema completo compatible con la función Beidou. Este producto puede buscar de forma independiente la navegación norte y también admite combinaciones de antena simple y doble. Equipado con excelentes algoritmos de fusión de navegación, optimizados para la oclusión de satélites, la interferencia por trayectos múltiples y otras situaciones.

El IF3700 adopta un sistema de bucle cerrado de alta precisión. giroscopio de fibra óptica con una temperatura total de 0,01°/h y un 20 μEl acelerómetro de cuarzo de alta precisión permite una medición de orientación inercial pura de alta precisión. Cuenta con función de brújula autónoma y mantiene la precisión de actitud y rumbo durante largos periodos sin asistencia externa. Puede utilizarse como equipo de navegación principal para vehículos aéreos no tripulados de gran tamaño, buques no tripulados y submarinos no tripulados, y se emplea ampliamente en campos relacionados como la aviación, la industria aeroespacial y la navegación.

Este producto está equipado con un giroscopio de fibra óptica de circuito cerrado de alta precisión con una temperatura total de 0,001 °/h y una 1Acelerómetro de cuarzo de alta precisión de 0 µg. Utiliza tecnología de fusión de datos multisensor para combinar la medición inercial con el GNSS, lo que permite una navegación integrada de alta precisión a largo plazo. El producto también cuenta con una función de posprocesamiento que permite mejorar la precisión de rumbo, actitud y posición mediante software especializado.

Este producto incorpora un giroscopio de fibra óptica de alta precisión de tres ejes, un acelerómetro flexible de cuarzo de alta precisión de tres ejes y un receptor GNSS multifrecuencia multimodo para topografía móvil, compatible con la función Beidou autónoma. Gracias a un algoritmo de navegación inteligente avanzado y al filtro de Kalman, se optimiza para la oclusión GNSS y la interferencia por trayectos múltiples, lo que permite medir con alta precisión la dirección, la actitud, la velocidad y la posición de los vehículos en movimiento.Este sistema de navegación inercial también cuenta con múltiples interfaces de sensores, como GNSS, odómetro, DVL y altímetro barométrico, que pueden satisfacer adecuadamente los requisitos de aplicaciones de navegación a largo plazo, de alta precisión y alta fiabilidad en entornos complejos como cañones urbanos, y puede utilizarse para la navegación y el control de diversos sistemas no tripulados.Las características del producto incluyen: determinación rápida y precisa del rumbo y la actitud iniciales, soporte para salida de rumbo y actitud en tiempo real, receptor GPS y Beidou de modo dual integrado, soporte para alineación rápida dinámica, diseño integrado de combinación INS/GNSS, soporte para posprocesamiento IE, algoritmo de filtro Kalman mejorado y resistencia a interferencias electromagnéticas y vibraciones. Puede utilizarse en navegación vehicular, aérea y marítima, control de estabilidad y otros campos.

Este artículo trata sobre los requisitos técnicos específicos relacionados con la norma IF4010 para la unidad de medición inercial tipo FOG-40, un tipo de unidad de medición inercial que puede utilizarse ampliamente en vehículos, buques, aeronaves y otros campos.

  The IF4030 fiber optic inertial navigation system primarily consists of a miniaturized fiber optic gyroscope, quartz flexible accelerometer, power supply module, acquisition and computation module, and satellite navigation module. It is characterized by its compact size, lightweight, and high precision, making it suitable for various applications such as small and medium-sized drones, electro-optical pods, and underwater robots. The main features are as follows: →  It has three accuracy levels: low, medium, and high, with self-north-finding accuracies of 0.5°, 0.25°, and 0.15°, respectively →  It features multiple working modes, including pure inertial, inertial/satellite combination, inertial/DVL combination, inertial/odometer combination, inertial/vision combination, and marine compass →  It possesses functions such as self-north-finding, transfer alignment, satellite-assisted moving-base alignment, high-precision post-processing, and heave measurement →  Built-in multiple communication protocols, with configurable serial port baud rate and output protocol →  Operating temperature: -45℃～+70℃ →  It features multiple interfaces such as RS422, RS232, Ethernet, and PPS input/output →  Power supply: 12V~36V, power consumption <12W →  Weight: 0.9kg →  Size: 80mm×80mm×84mm

The IF4030S fiber optic inertial navigation system primarily consists of a miniaturized fiber optic gyroscope, quartz flexible accelerometer, power supply module, acquisition and computation module, and satellite navigation module. It is characterized by its compact size, lightweight, and high precision, making it suitable for various applications such as small and medium-sized drones, electro-optical pods, and underwater robots. The main features are as follows: → It has three accuracy levels: low, medium, and high, with self-north-finding accuracies of 0.5°, 0.25°, and 0.15°, respectively → It features multiple working modes, including pure inertial, inertial/satellite combination, inertial/DVL combination, inertial/odometer combination, inertial/vision combination, and marine compass → It possesses functions such as self-north-finding, transfer alignment, satellite-assisted moving-base alignment, high-precision post-processing, and heave measurement → Built-in multiple communication protocols, with configurable serial port baud rate and output protocol → Operating temperature: -45℃～+70℃ → It features multiple interfaces such as RS422, RS232, Ethernet, and PPS input/output →  Power supply: 12V~36V, power consumption <12W → Weight: 0.9kg   →  Size: 110mm×80mm×55mm

IF4050 fiber optic inertial navigation system is mainly composed of miniaturized fiber optic gyroscope, MEMS accelerometer, satellite navigation module, main processing board, etc. It has the characteristics of small size, light weight, and low cost, and is suitable for various applications such as small and medium-sized unmanned aerial vehicles, electro-optical pods, underwater robots, etc. The main features are as follows: →  Automatic North Finding with an accuracy of up to 0.5 ° →  Multiple working modes including pure inertia, inertia/satellite combination, inertia/DVL combination, inertia/mileage combination, inertia/vision combination, and marine compass →  Automatic North Finding, transfer alignment, satellite assisted dynamic base alignment, high-precision post-processing, and other functions →  Built in multiple communication protocols, both serial port baud rate and output protocol can be configured →  Working temperature: -45℃ ~ +70 ℃ →  Equipped with multiple interfaces such as RS422, RS232, Ethernet, PPS input/output, etc →  Power supply: 12V~36V, power consumption <12W →  Weight: 0.65kg   →  Size: 80mm × 80mm × 70mm

The IF4060 fiber optic inertial navigation system primarily consists of a miniaturized fiber optic gyroscope, quartz flexible accelerometer, power supply module, acquisition and computation module, and satellite navigation module. It is characterized by its compact size, lightweight, and high precision, making it suitable for various applications such as small and medium-sized drones, electro-optical pods, and underwater robots. The main features are as follows: →  It has three accuracy levels: low, medium, and high, with self-north-finding accuracies of 0.2°, 0.1°, and 0.06°, respectively →  It features multiple working modes, including pure inertial, inertial/satellite combination, inertial/DVL combination, inertial/odometer combination, inertial/vision combination, and marine compass →  It possesses functions such as self-north-finding, transfer alignment, satellite-assisted moving-base alignment, high-precision post-processing, and heave measurement →  Built-in multiple communication protocols, with configurable serial port baud rate and output protocol →  Operating temperature: -45℃～+70℃ →  It features multiple interfaces such as RS422, RS232, Ethernet, and PPS input/output →  Power supply: 12V~36V, power consumption <12W →  Weight: 1.8kg   →  Size: 118mm×104mm×117mm

The IF4070 fiber optic inertial navigation system primarily consists of a miniaturized fiber optic gyroscope, quartz flexible accelerometer, power supply module, acquisition and computation module, and satellite navigation module. It is characterized by its compact size, lightweight, and high precision, making it suitable for various applications such as small and medium-sized drones, electro-optical pods, and underwater robots. The main features are as follows: →  North-seeking accuracy up to 0.08°; →  Supports multiple working modes including pure inertial, inertial/satellite integrated, inertial/DVL integrated, inertial/odometer integrated, inertial/vision integrated, and marine gyrocompass mode; →  Equipped with functions such as automatic north-seeking, transfer alignment, satellite-aided moving base alignment, high-precision post-processing, and heave measurement; →  Built-in shock absorber for adaptability to vibration environments; →  Built-in memory card for measurement data storage, accessible via USB or network port; →  Embedded with multiple communication protocols; serial port baud rate and output protocol are configurable; →  Operating temperature: -45℃～+60℃; →  Equipped with multiple interfaces including RS422, RS232, Ethernet, and PPS input/output; →  Power supply: 12V～36V, power consumption ＜15W; →  Weight: 2.6kg; →  Dimensions: 132mm×116mm×119mm (excluding connectors and mounting lugs)

The IF5000 fiber optic inertial navigation system primarily consists of a miniaturized fiber optic gyroscope, quartz flexible accelerometer, power supply module, acquisition and computation module, and satellite navigation module. It is characterized by its compact size, lightweight, and high precision, making it suitable for various applications such as small and medium-sized drones, electro-optical pods, and underwater robots. The main features are as follows: →  North-seeking accuracy up to 0.05°; →  Supports multiple working modes including pure inertial, inertial/satellite integrated, inertial/DVL integrated, inertial/odometer integrated, inertial/vision integrated, and marine gyrocompass mode; →  Equipped with functions such as automatic north-seeking, transfer alignment, satellite-aided moving base alignment, high-precision post-processing, and heave measurement; →  Built-in shock absorber for adaptability to vibration environments; →  Built-in memory card for measurement data storage, accessible via USB or network port; →  Embedded with multiple communication protocols; serial port baud rate and output protocol are configurable; →  Operating temperature: -45℃～+60℃; →  Equipped with multiple interfaces including RS422, RS232, Ethernet, and PPS input/output; →  Power supply: 12V～36V, power consumption ＜15W; →  Weight: 2.6kg;   →  Dimensions: 132mm×116mm×119mm (excluding connectors and mounting lugs)
